The new type of ampoule coating printing machine is used to print ampoule and after to be packed in middle size package, like 50pcs/100pcs etc.

Different from previous ampoule printing, printed ampoules are discharged vertically, so when ampoules are transferred to tray filling machine, it can be accurately grabbed by robot arm.

There is visual inspection component at the discharge port, it can detect whether the printing is complete or not. After printed and detected, ampoules will be transferred to plastic tray filling machine, the robot arm will grab the corresponding  amount of ampoules into the middle size plastic tray for example 100 pcs.

Technical Parameter

Power : 10 kW

Voltage : AC 220 V / 50 Hz

Speed : 1-2ml 48,000-52,000 pcs/h, 5ml 30,000 pcs/h, 10-20ml 25,000 pcs/h

Weight : 5,000 kg

Dimension : 3,898 mm x 1,269 mm x 1,840 mm

Printer Image

Printing Sample
